2B | Plug - Straight | Solder / Clamp
Browse for other connectors
▣
Product Overview
Part Number
15B-2B-16-72
Series
2B
Style
Plug - Straight
Description
2B Cable Fixing Plug, 16 x Male Contacts, Chrome Plated. 6.3 to 7.2 mm Cable.
Primary Fixing
Solder / Clamp
▣
Specifications
Electrical
Contact Resistance
5.5 mOhm (After 1000 Mating Cycles)
Rated Current
4.5 Amp
Screening Continuity
2.0 mOhm (Body shell to shell)
Test Voltage
500 Volts
Environmental
IP Rating
IP50
Temperature Range
-45 to +125 degrees C
Material
Body
Brass, Matt Chrome Plated
Contact Block
PPS
Mechanical
Contact Gender
Male
Durability
>5000 Mating Cycles
To Fit Cable Types
16 Core. Max Conductor 22AWG. Cable Jacket O.D 6.3-7.2mm
▣
Documents
Promotional Material
B Series Brochure
Conformance Document
Certificate of Conformance
Compliance Document
REACH Policy and Statement
Compliance Document
RoHS Certificate of Compliance
▣
Order
UK stock 48
Pending 0
Minimum order quantity 1
▣
Pricing
1 off £20.37 each
10 off £16.53 each
50 off £15.87 each
100 off £14.55 each
300 off £14.28 each
▣
Order
UK stock 48
Pending 0
Minimum order quantity 1
▣
Pricing
1 off £20.37 each
10 off £16.53 each
50 off £15.87 each
100 off £14.55 each
300 off £14.28 each
▣
Product Overview
Part Number
15B-2B-16-72
Series
2B
Style
Plug - Straight
Description
2B Cable Fixing Plug, 16 x Male Contacts, Chrome Plated. 6.3 to 7.2 mm Cable.
Primary Fixing
Solder / Clamp
▣
Specifications
Electrical
Contact Resistance
5.5 mOhm (After 1000 Mating Cycles)
Rated Current
4.5 Amp
Screening Continuity
2.0 mOhm (Body shell to shell)
Test Voltage
500 Volts
Environmental
IP Rating
IP50
Temperature Range
-45 to +125 degrees C
Material
Body
Brass, Matt Chrome Plated
Contact Block
PPS
Mechanical
Contact Gender
Male
Durability
>5000 Mating Cycles
To Fit Cable Types
16 Core. Max Conductor 22AWG. Cable Jacket O.D 6.3-7.2mm
▣
Documents
Promotional Material
B Series Brochure
Conformance Document
Certificate of Conformance
Compliance Document
REACH Policy and Statement
Compliance Document
RoHS Certificate of Compliance
