Part Number

BN02-0223-L06-2

Series

Style

Jack - Bulkhead

Description

BNC Clamp Bulkhead Jack, Nickel Plated, Compression Fixing, RG58, LBC195, RG223, RG400

Primary Fixing

Compression Clamp

▣

Specifications

Electrical

Dielectric Withstanding

1500 Volts RMS Maximum

Impedance

50 ohms

Interface Frequency

4 GHz

Working Voltage

500 Volts RMS Maximum

Environmental

RoHS Compliant

Yes

Temperature Range

-55 to +85 degrees C

Material

Backnut

Brass, Nickel Plated

Body

Brass, Nickel Plated

Contact

Brass, Gold Plated

Dielectric

PTFE

Gasket

Rubber

Top Hat

Brass, Nickel Plated

Washer

Brass, Nickel Plated

Mechanical

Cable Retention

Equal to breaking strain of cable

Durability

500 mating cycles

Fixing Method

Clamp

Maximum Panel Thickness

5.00mm

▣

Cable Preparation

A =	7.50mm
B =	2.00mm
C =	5.50mm

▣
