BNC | Jack - Flange | Direct Solder
Browse for other connectors Configure in Cabulator
▣
Product Overview
Part Number
BN06-0405-R06-2
Series
BNC
Style
Jack - Flange
Description
BNC 4 Hole Flange Jack, 17.5mm with O ring, Nickel Plated, RG405 conformable
Primary Fixing
Direct Solder
▣
Specifications
Electrical
Dielectric Withstanding
1500 Volts RMS Maximum
Impedance
50 ohms
Interface Frequency
11 GHz
Working Voltage
500 Volts RMS Maximum
Environmental
RoHS Compliant
Yes
Temperature Range
-65 to +165 degrees C
Material
Body
Brass, Nickel Plated
Contact
Phosphor Bronze, Gold Plated
Dielectric
PTFE
O Ring
Silicone
Mechanical
Cable Retention
272N
Contact Retention
27N
Durability
500 mating cycles
Fixing Method
Solder
▣
Cable Preparation
A = 0.00mm
B = 3.50mm
S4_R
▣
Documents
Conformance Document
Certificate of Conformance
Datasheet Icon
Datasheet
Compliance Document
REACH Policy and Statement
Compliance Document
RoHS Certificate of Compliance
▣
Order
UK stock 295
Pending 0
Minimum order quantity 1
▣
Pricing
1 off €12,80 each
10 off €10,23 each
50 off €9,30 each
100 off €8,83 each
300 off €8,41 each
▣
Order
UK stock 295
Pending 0
Minimum order quantity 1
▣
Pricing
1 off €12,80 each
10 off €10,23 each
50 off €9,30 each
100 off €8,83 each
300 off €8,41 each
▣
