BNC | Jack - Straight | Crimp
Product Overview
Part Number
BN10-0178-C06
Series
Description
BNC Crimp Jack, Integral Contact, Nickel Plated, PTFE Dielectric, RG178
Primary Fixing
Specifications
Electrical
Dielectric Withstanding
1500 Volts RMS Maximum
Interface Frequency
4 GHz
Working Voltage
500 Volts RMS Maximum
Environmental
RoHS Compliant
Yes
Temperature Range
-65 to +165 degrees C
Material
Body
Brass, Nickel Plated
Contact
Brass, Gold Plated
Dielectric
PTFE
Ferrule
Brass, Nickel Plated
Insulator
PTFE
Pin
Brass, Gold Plated
Tube
Brass, Nickel Plated
Mechanical
Cable Retention
Equal to breaking strain of cable
Durability
500 mating cycles
Fixing Method
Crimp
Cable Preparation
A = 8.00mm
B = 2.00mm
C = 2.50mm
S1_R
Tooling
Crimp Die Sizes
0.72mm sq.
3.25mm hex.
Documents
Order
UK stock 133
Pending 0
Minimum order quantity 1
Pricing
1 off $3.56 each
10 off $2.85 each
50 off $2.59 each
100 off $2.46 each
300 off $2.34 each
Order
UK stock 133
Pending 0
Minimum order quantity 1
Pricing
1 off $3.56 each
10 off $2.85 each
50 off $2.59 each
100 off $2.46 each
300 off $2.34 each
