Coaxial Connector BN15-0214-L06 - BNC Clamp Plug, Nickel Plated, Taper Fixing, RG214

Browse for other connectors

▣

Product Overview

Part Number

BN15-0214-L06

Series

BNC

Style

Plug - Straight

Description

BNC Clamp Plug, Nickel Plated, Taper Fixing, RG214

Primary Fixing

Taper Clamp

▣

Specifications

Electrical

Dielectric Withstanding

1500 Volts RMS Maximum

Impedance

50 ohms

Interface Frequency

4 GHz

Working Voltage

500 Volts RMS Maximum

Environmental

RoHS Compliant

Yes

Temperature Range

-55 to +85 degrees C

Material

Backnut

Brass, Nickel Plated

Body

Brass, Nickel Plated

Coupling Nut

Brass, Nickel Plated

Dielectric

Delrin

Gasket

Rubber

Brass, Gold Plated

Taper Clamp

Brass, Nickel Plated

Washer

Brass, Nickel Plated

Mechanical

Cable Retention

Equal to breaking strain of cable

Durability

500 mating cycles

Fixing Method

Clamp

▣

Cable Preparation

A =	10.00mm
B =	5.50mm
C =	4.50mm

▣

Documents

Certificate of Conformance

Datasheet

REACH Policy and Statement

RoHS Certificate of Compliance

▣
