SMA
|
Jack - Bulkhead
|
Direct Solder
Browse for other connectors
Configure in Cabulator
IPX Assemblies for coaxial cables; 0.81mm to 1.83mm
▣
Product Overview
Part Number
MA02-0083-R01-8
Series
SMA
Style
Jack - Bulkhead
Description
SMA Solder Bulkhead Jack, Gold Plated, 8mm Hexagonal Flange, 1.13mm Cable
Primary Fixing
Direct Solder
▣
Specifications
Electrical
Dielectric Withstanding
750 Volts RMS Maximum
Impedance
50 ohms
Interface Frequency
12.4 GHz
Working Voltage
335 Volts RMS Maximum
Environmental
RoHS Compliant
Yes
Temperature Range
-65 to +165 degrees C
Material
Body
Brass, Gold Plated
Contact
Beryllium Copper, Gold Plated
Dielectric
PTFE
Ferrule
Brass, Gold Plated
Locknut
Brass, Gold Plated
Washer
SS41, Gold Plated
Mechanical
Cable Retention
Equal to breaking strain of cable
Durability
500 mating cycles
Fixing Method
Solder
Maximum Panel Thickness
2.50mm
▣
Documents
Certificate of Conformance
REACH Policy and Statement
RoHS Certificate of Compliance
▣
Order
Some elements of the ordering process are restricted for this product as a minimum production quantity or other limiting factors may apply.
For assistance please call or email our technical sales team.
IPX Assemblies for coaxial cables; 0.81mm to 1.83mm
▣
Order
Some elements of the ordering process are restricted for this product as a minimum production quantity or other limiting factors may apply.
For assistance please call or email our technical sales team.
▣
Product Overview
Part Number
MA02-0083-R01-8
Series
SMA
Style
Jack - Bulkhead
Description
SMA Solder Bulkhead Jack, Gold Plated, 8mm Hexagonal Flange, 1.13mm Cable
Primary Fixing
Direct Solder
▣
Specifications
Electrical
Dielectric Withstanding
750 Volts RMS Maximum
Impedance
50 ohms
Interface Frequency
12.4 GHz
Working Voltage
335 Volts RMS Maximum
Environmental
RoHS Compliant
Yes
Temperature Range
-65 to +165 degrees C
Material
Body
Brass, Gold Plated
Contact
Beryllium Copper, Gold Plated
Dielectric
PTFE
Ferrule
Brass, Gold Plated
Locknut
Brass, Gold Plated
Washer
SS41, Gold Plated
Mechanical
Cable Retention
Equal to breaking strain of cable
Durability
500 mating cycles
Fixing Method
Solder
Maximum Panel Thickness
2.50mm
▣
Documents
Certificate of Conformance
REACH Policy and Statement
RoHS Certificate of Compliance
▣
Associated Products
◄
►
MA15-X1-A23
SMA Dust Cap, IP67, Black Chrome
Details
